Offline Installation and Usage of Metax GPU Components¶

This section provides guidance on the offline installation of Metax components such as metax-gpu-extensions and metax-operator, as well as instructions for using Metax GPU cards.

Prerequisites¶

• DCE 5.0 container management platform has been deployed and is functioning properly.
• The container management module has either joined an existing Kubernetes cluster or created a new one, and the UI interface of the cluster is accessible.
• The GPU cards in the current cluster are not virtualized and are not in use by other applications.
• The image registry has imported the Addon offline installation package. For usage, refer to Using the Addon offline installation package.

Component Overview¶

DCE 5.0 ships with two built-in Helm chart packages: metax-gpu-extensions and metax-operator. Choose which to install based on your usage scenario.

1. metax-gpu-extensions: Contains the gpu-device and gpu-label components. When using the Metax-extensions solution, application container images must be built based on the MXMACA® base image. This solution only supports the full GPU usage scenario.
2. metax-operator: Contains the gpu-device, gpu-label, driver-manager, container-runtime, and operator-controller components. With this approach, you can build application container images that do not include the MXMACA® SDK. It supports both full GPU and vGPU scenarios.

Procedure¶

1. In the left navigation bar, go to Container Management -> Cluster Management, and click the name of the target cluster.
2. From the left navigation bar, click Helm Apps -> Helm Templates, then search for metax.
3. The following two components will appear. Install them selectively as needed.
